DS8023-RJX Integrated Circuit Chip Low-Power Smart Card Interface IC TSSOP-28
DS8023-RJX Integrated Circuit Chip Low-Power Smart Card Interface IC TSSOP-28
Beschrijving
Part Number:
DS8023-RJX
Supply Voltage - Min::
2.7 V
Supply Voltage - Max::
6 V
Operating Supply Current::
500 uA
Minimum Operating Temperature::
- 40 C
Maximum Operating Temperature::
+ 85 C
Markeren:
DS8023-RJX
,
DS8023-RJX Integrated Circuit Chip
,
Low-Power Smart Card Interface IC
DS8023-RJX Integrated Circuit Chip Low-Power Smart Card Interface IC TSSOP-28
Product Description Of DS8023-RJX
DS8023-RJX smart card interface IC is a low-cost, low-power, analog front-end for a smart card reader designed for all ISO 7816, EMV, and GSM11-11 applications. The DS8023-RJX supports 5V, 3V, and 1.8V smart cards, and provides an option for ultra-low stop-mode power consumption. The DS8023-RJX is available in 28-pin TSSOP packages, and can often be used as a replacement for the TDA8024 with little or no application changes.
DS8023-RJX is designed to interface between a system microcontroller and the smart card interface, providing all power supply, protection, and level shifting required for IC card applications.
Specifications Of DS8023-RJX
2.7 V
6 V
500 uA
- 40 C
+ 85 C
700 mW
Unit Weight:
403 mg
Features Of DS8023-RJX
Analog Interface and Level Shifting for IC Card Communication
±8kV (min) ESD (IEC) Protection on Card Interface Pins
Ultra-Low Stop-Mode Current, Less Than 10nA (typ)
Internal IC Card-Supply Voltage Generation
5.0V ±5%, 80mA (max)
3.0V ±8%, 65mA (max)
1.8V ±10%, 30mA (max)
Automatic Card Activation and Deactivation Controlled by Dedicated Internal Sequencer
I/O Lines from Host Directly Level Shifted for Smart Card Communication
Flexible Card Clock Generation, Supporting External Crystal Frequency Divided by 1, 2, 4, or 8
High-Current/Short-Circuit and High-Temperature Protection
Applications Of DS8023-RJX
Access Control
Automated Teller Machines
Banking Applications
Debit/Credit Payment Terminals
Pay/Premium Television
PIN Pads
POS Terminals
Set-Top Box Conditional Access
Telecommunications
Other Electronic Components In Stock
Part Number
Package
2EDR6259X
DSO-14
PMC41420
QFN
PXE1211CPMG003
VQFN-40
PMC41430
QFN
PXC1331CPNG003
QFN
TLE9868QXB20
VQFN-48
IPA95R450PFD7
TO220-3
ICC80QSG
DSO-8
ICE5QR1680BG
DSO-12
ICE2QR2280Z
DIP-7
ICE2QR0680Z
DIP-7
ICE3BR4765JG
DSO-12
ICE5QR4780BG
DSO-12
ICE5QR0680BG
DSO-12
ICE2QR4765G
DSO-12
XDPS2201D
DSO-14
CYPD3184A1-24LQXQ
VQFN-24
CYPAS111A1-24LQXQ
VQFN-24
XDPS2201V
DSO-14
CYPAP112A3-10SXQ
DSO-10
CYPAP211A1-14SXI
DSO-14
CYPAP212A1-14SXI
DSO-14
ILD8150E
DSO-8
IM66D120A
TLGA-5
IM66D130A
TLGA-5
IMBG65R007M2H
TO263-7
IMBG65R015M2H
TO263-7
IMBG65R020M2H
TO263-7
CYPD727268LQXQ
VQFN-68
IMBG65R040M2H
TO263-7
